Артикул:
IKVM-210-08
| Hardware | |||||||
|---|---|---|---|---|---|---|---|
| Number of Ports | 8 D-sub ports (15-pin) | ||||||
| Maximum Control of PCs | 64 by 2-tier star-type cascading (KVM-210-08 x 8) | ||||||
| PC Ports |
|
||||||
| Console Ports |
|
||||||
| LED |
|
||||||
| Button |
|
||||||
| Remote Console | 1 RJ45 port for 10/100/1000BASE-T | ||||||
| Video Resolution |
Local side: 2048 x 1536 (max) Remote side: 1920 x 1080 (max) |
||||||
| Housing | Metal | ||||||
| Dimensions (W x D x H) | 432 x 155 x 44 mm | ||||||
| Weight | 2.22kg | ||||||
| Power Requirement | 9V DC, 1A | ||||||
| Installation | 1U rack-mountable, desktop | ||||||
| Management | |||||||
| Supported Protocol | TCP, IP, HTTP | ||||||
| Client Software | IPKVM Software | ||||||
| PC Selection |
Port select button Hotkeys on keyboard OSD (on screen display) |
||||||
| Scan Interval | 5~60 seconds | ||||||
| Security |
User password and super password DES, AES and 3DES |
||||||
| Environment & Certification | |||||||
| Operating Temperature | -10 ~ 50 degrees C | ||||||
| Storage Temperature | -20 ~ 60 degrees C | ||||||
| Operating Humidity | 0 ~ 90% | ||||||
| Regulatory | CE, FCC | ||||||
